Inputs: 12× 4K60 (4× HDMI 2.0, 4× HDMI 2.0/DP 1.2, 4× 12G-SDI); HDR10, HLG, SDR

Outputs: 8× HDMI 2.0 main, 8× 10G SFP fiber, 4× HDMI 2.0 flex, 4× 12G-SDI matrix, 2× multiviewer

Processing: 4K60 4:4:4 10-bit; 8 main layers + 4 PIP layers; about 1 frame of latency

Effects: Chroma, luma and smart key; cut and fill; masks; edge blending; bezel compensation

Canvas: Up to 8192 px wide or 7680 px tall

Audio: Redundant Dante, 64×64 channels, AES67; embedding and de-embedding on every input and output

Control: 7" touchscreen, U5/U5 Pro, PixelFlow, Stream Deck via Companion

Reliability: Redundant Gigabit control ports, genlock with loop-through, 256 presets

Includes: Roadcase
